- Condition:New
- Type:Filling Machine
- Machinery Capacity:Other, 2000BPH, 3000BPH
- Applicable Industries:Hotels, Manufacturing Plant, Food & Beverage Factory, Restaurant, Home Use, Retail, Food Shop, Food & Beverage Shops, Other
- Showroom Location:None
- Application:Beverage, Chemical, Food, Automatic coffee capsule filling and sealing machine
- Packaging Type:K-CUP, Nespresso, Dolce Gusto, etc.
- Packaging Material:Plastic, Paper, Metal
- Automatic Grade:Automatic
- Driven Type:Pneumatic
- Voltage:380V
- Place of Origin:Shanghai, China
- Brand Name:JOYGOAL
- Dimension(L*W*H):1300*1200*2000 mm
- Weight:800 KG
- Warranty:1 Year
- Key Selling Points:High-accuracy
- Filling Material:Powder
- Filling Accuracy:±0.1g
- Machinery Test Report:Not Available
- Video outgoing-inspection:Provided
- Warranty of core components:1 Year
- Core Components:Motor, Other, PLC, Gear, Gearbox, Engine
- Name:Coffee Capsule Filling Sealing Machine
- Filling heads:1
- Top capacity:3000 cups/hour
- Filling volume:1 – 30 (can be adjusted)
- Air:0.7 m3 /min
- After Warranty Service:Spare parts
- Local Service Location:South Korea
- After-sales Service Provided:Field maintenance and repair service
- Certification:CE
- Marketing Type:New Product 2020
- Supply Ability
- 100 Set/Sets per Month Automatic coffee capsule filling and sealing machine
- Packaging Details
wooden case for JOYGOAL new product high speed Rotary Type Coffee Powder Filling Sealing Machine for K-Cup or Nespresso
- Port
Shanghai port
- Lead time:Quantity(sets)1 – 1>1Lead time (days)45To be negotiated
Related Products
We have empty coffee capsules ,filters and lids,auto matic coffee capsule filling and sealing machine for K–CUP,Nespresso,Dolce Gusto,etc.
Product Description
| Model | KFZ-1 |
| Type | Rotary |
| Filling heads | 1 |
| Production capacity | 3000 capsules/hour |
| Filling volume | 1-30g (can be adjusted) |
| Error | ±0.1g |
| Power | 2.5kw |
| Air | 0.7m³/min |
| Power sourse | 380V 50HZ |
| Weight | 800kg |
| Dimension | 1300*1200*2000mm |
Particular Advantages
1.Stable performance ,high profile Eurpe standard
2.One key operation,real-time monitoring
3.Servo drive and the high precision high-speed positioning movements
4.Protection acrylic dust cover
5.High accrucacy filling performance by servo motor,less than ±0.1gram
6.High performance nitrogen flushing,nitrogen percentage in sealed capsule more than 95-98%
7.Full set of Ormon control system,network system can realize transtegional and supranational to monitor
8.All parts contact with ground coffee are made of SUS304
9.Full welding and polish treatment hopper,easy to cleaning
10.No capsule not filling detecor,no lid alarm detector,air cylinder return postion detector
11.Failures arise display on HMI automatic
2.One key operation,real-time monitoring
3.Servo drive and the high precision high-speed positioning movements
4.Protection acrylic dust cover
5.High accrucacy filling performance by servo motor,less than ±0.1gram
6.High performance nitrogen flushing,nitrogen percentage in sealed capsule more than 95-98%
7.Full set of Ormon control system,network system can realize transtegional and supranational to monitor
8.All parts contact with ground coffee are made of SUS304
9.Full welding and polish treatment hopper,easy to cleaning
10.No capsule not filling detecor,no lid alarm detector,air cylinder return postion detector
11.Failures arise display on HMI automatic
Introduction
this machine is specially designed for coffee powder product (or other kinds of powder products,such as cocoa powder,milk powder etc.)to be filled and sealed inside empty plastic nespresso capsule.
Based on touch screen control width English(or other languages) and Chinese language,it is convenient and reliable.It is a kind of program-controlled machine that is universal and functional.Features are compact structure,high automation,easy to use,stable performance,simple maintenance,and hight production efficiency and 24-hour continuous work.
Based on touch screen control width English(or other languages) and Chinese language,it is convenient and reliable.It is a kind of program-controlled machine that is universal and functional.Features are compact structure,high automation,easy to use,stable performance,simple maintenance,and hight production efficiency and 24-hour continuous work.
