- Condition:New
- Type:Filling Machine, Linear type
- Machinery Capacity:8000BPH, Other, 10800BPH
- Applicable Industries:Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
- Showroom Location:None
- Application:APPAREL, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Textiles, coffee capsule filling machine
- Packaging Type:Bags, Barrel, Bottles, CANS, Capsule, Cartons, case, Pouch, Stand-up Pouch, K-CUP, Nespresso, Dolce Gusto, etc.
- Packaging Material:Glass, Metal, Paper, Plastic, Wood
- Automatic Grade:Automatic
- Driven Type:Pneumatic
- Voltage:AC 220/380V
- Place of Origin:Shanghai, China
- Brand Name:JOYGOAL
- Dimension(L*W*H):4000*1650*2200 mm
- Weight:1100 KG
- Warranty:1 Year
- Key Selling Points:High speed
- Filling Material:Powder
- Filling Accuracy:99%, ± 0.1g
- Machinery Test Report:Not Available
- Video outgoing-inspection:Provided
- Warranty of core components:1 Year
- Core Components:Motor, Other, PLC, Gear, Gearbox, Engine
- Name:Automatic Coffee Capsule Filling Sealing Machine
- Model:KFP-6
- Filling nozzles:6
- Top capacity:4000-5000 capsules/hour
- Filling volume:1 – 30 (can be adjusted)
- Air consumption:0.7 m3 /min
- Temperature:0-400 °C
- After Warranty Service:Video technical support
- Marketing Type:New Product 2020
- Supply Ability
- 100 Set/Sets per Month coffee capsule filling machine
- Packaging Details
wooden case
- Port
Shanghai port
- Lead time:Quantity(sets)1 – 10>10Lead time (days)45To be negotiated
AUTOMATIC COFFEE CAPSULE FILLING AND SEALING MACHINE FOR K-CUP
Capsule cup filling & sealing machines for Tea and Coffee
With the maximum degree of quality, the machine has attained a maximum rate of 2500-3000 times an hour per nozzle in China now. Combined with world complex technology with our institution’s upgrade technologies, the system has multiple patents. It’s well-welcomed by clients at home and overseas.
Coffee capsule filling and sealing machine chief features
Little Dimensions, higher rate capability, complete capabilities and completely automatic, High precise engine powered by servo motor, PLC control and real-time tracking, Nitrogen system: flush capsule, No cup no filling without a sealing (continues generation no pause)We have empty coffee capsules, filter, and lid, coffee capsule filling sealing machine for K-CUP, Nespresso, Dolce Gusto, etc.
| Model | KFP-6 |
| Type | Linear type |
| Filling heads | 6 heads |
| Capacity | 10800 per/hour |
| Filling volume | 1-30g(adjustable) |
| Power | 5.5kw |
| Air | 0.7 m³/min |
| Weight | 1600kg |
| Power source | 380V(cusomize) |
| Dimension | (L)3300*(W)*1800(H)*2200(MM) |
| Error | ±0.01 |
